PRINCIPAL PARTICULARS
Length over all90.00 m
Length between p.p.83.08 m
Breadth moulded19.00 m
Depth7.25 m
Draught5.85 m
Deadweight (T= 5.85)5490 ton
Dredging draught6.70 m
Deadweight (T= 6.70)6800 ton
GT4082
Speed (service)11 kn
EQUIPMENT
Main engine (total output)3000 kW
2 x Rudder propeller, each1500 kW
Bow thruster500 kW
DREDGING PARTICULARS
Diameter of dragarm900 mm
Max. dredge depth30 m
Sand pump output1680 kW
Jet pump output2 x 750 kW
Hopper capacity4500 m3
Density of hopper load1.0 – 2.2 t/m3
CAPACITIES
Gasoil384 m3
Potable water83 m3
Ballast water290 m3
